FR220 Excavator
Technical features of FR220
1. Optional imported Isuzu engine from Japan, low fuel consumption, low noise, environmental protection and high efficiency.;
2. Adopted world-classKawasakihydraulic system, high efficient and reliable;
3. High strength structural parts are purchased from the same channels as the world-known brands;
4. Safe and comfortable driving cab;
5. Improved operating performance by many self-owned patented technologies.
|
Parameter Items |
Parameter Value |
|
1.The main parameters |
|
|
Operating weight(kg) |
21800 |
|
Standard bucket capacity(m3) |
0.92 |
|
Transport dimensions (L × W × H) mm |
9380x2980x3030 |
|
Bucket digging force (kN) |
138 |
|
Stick digging force( kN) |
126 |
|
Maximum traction power (kN) |
174 |
|
2.Walking device |
|
|
High and low speed （km / h） |
5.3/3.5 |
|
Grade ability(°) |
30 |
|
Ground pressure (kpa) |
46 |
|
3.Rotating device |
|
|
Rotating Speed (rpm) |
12.3 |
|
4.Engine |
|
|
Model |
6BTAA5.9-C150 Cummins |
|
Type |
6cylinder, in-line,four-stroke,direct injection, turbocharged intercooled |
|
Rated power / speed (KW / rpm) |
112/1950 |
|
Bore × stroke（mm） |
102×120 |
|
Displacement （L） |
5.88 |
|
Fuel consumption（g / kW • h） |
221 |
|
Fuel tank capacity |
380 |
|
5.Hydraulic system |
|
|
Main pump pressure （Mpa） |
31.4/34.3 |
|
Main pump flow （L / min） |
230×2 |
|
6.Operation range |
|
|
Maximum digging height（mm） |
10220 |
|
Maximum unloading height（mm） |
7260 |
|
Maximum digging depth（mm） |
6620 |
|
Maximum digging radius（mm） |
9900 |
|
Bulldozing Blade size （L × W ）mm |
/ |
